Strain Gages for Measuring Axial Tension of Bolts
Overview
If it is difficult to bond a strain gage to the surface of a bolt for measuring the tightening stress, these gages enable the measurement by embedding into a hole, 2 mm in diameter, bored from the top head of the bolt.

Click here for details.
Technical Information
Major Properties
Materials Resistive element CuNi alloy foil
Materials Base Polyimide
Operating temperature in combination with major adhesives after curing (°C) EP-370: Normal temp. to 50ºC
Operating temperature in combination with major leadwire cables (°C) φ0.14 Polyester-coated copper cable 5 cm long
Self-temperature-compensation (°C) -
Applicable linear expansion coefficients (×10^-6/℃) -
Strain limits at normal temp. (approx. %) -
Fatigue lives at normal temp. (times) -
Remarks
Bore diameter 2
*We have offered service with our sophisticated bonding work of strain gage onto bolts provided by our customers.
