| Major Properties | |
|---|---|
| Materials Resistive element | N type Si |
| Materials Base | Polyimide |
| Operating temperature in combination with major adhesives after curing (°C) |
EP-340: -50 to 150ºC CC-33A: -50 to 120ºC CC-36: -30 to 100ºC EP-17: -50 to 150ºC (for E5) |
| Operating temperature in combination with major leadwire cables (°C) |
Silver-covered copper wires: -50 to 150ºC Oxygen-free tin-plated copper wires: -50 to 150ºC |
| Self-temperature-compensation (°C) | 20 to 50ºC |
| Applicable linear expansion coefficients (×10^-6/℃) | 11, 16 |
| Strain limits at normal temp. (approx. %) | 0.1 |
| Fatigue lives at normal temp. (times) | 2x10^6 (Reference value, ±1000μm/m, normal temp.) |
