| NHTSA-3500-A |
|---|
| Qty per Assem | New reference number for Part | Description | Published NHTSA Drawing No. | Det. |
|---|---|---|---|---|
| - | This item is not provided as part of the Assem | Interface to Vehicle | 1 | |
| 4 | NHTSA-10-2 | Universal Vehicle Adaptor | U-V-A #2 | 2 |
| 4 | NHTSA-3500-3 | Face Plate | H-V #2 | 3 |
| 4 | NHTSA-3500-4 | Outrigger Retainer Cap | O-R-C #2 | 4 |
| 2 | NHTSA-3500-5 | Outrigger | S-O #1 | 5 |
| 4 | NHTSA-3500-6 | Outrigger Table | H-V #1 | 6 |
| 1 | NHTSA-10-7K | Hardware Kit | R-B-A #2 & O-E-A #1 | All nuts, bolts, and washers as called out |
| 4 | NHTSA-10-8 | Skid Pad | H-S-P #1 | Hemispherical Outrigger Skid Pad |
| 4 | INHTSA-10-9 | Skid Pad adaptor | O-S-P-A #1 | Hemispherical Outrigger Skid Pad adaptor |
| NHTSA-6000-A |
|---|
| Qty per Assem | New reference number for Part | Description | Published NHTSA Drawing No. | Det. |
|---|---|---|---|---|
| - | This item is not provided as part of the Assem | Interface to Vehicle | 1 | |
| 4 | NHTSA-10-2 | Universal Vehicle Adaptor | U-V-A #2 | 2 |
| 4 | HTSA-6000-3 | Face Plate | H-V #2 | 3 |
| 4 | NHTSA-6000-4 | Outrigger Retainer Cap | O-R-C #2 | 4 |
| 2 | NHTSA-6000-5 | Outrigger | S-O #1 | 5 |
| 4 | NHTSA-6000-6 | Outrigger Table | H-V #1 | 6 |
| 1 | NHTSA-10-7K | Hardware Kit | R-B-A #2 & O-E-A #1 | All nuts, bolts, and washers as called out |
| 4 | NHTSA-10-8 | Skid Pad | H-S-P #1 | Hemispherical Outrigger Skid Pad |
| 4 | INHTSA-10-9 | Skid Pad adaptor | O-S-P-A #1 | Hemispherical Outrigger Skid Pad adaptor |
| NHTSA-6000-6 |
|---|
| Qty per Assem | New reference number for Part | Description | Published NHTSA Drawing No. | Det. |
|---|---|---|---|---|
| - | This item is not provided as part of the Assem | Interface to Vehicle | 1 | |
| 4 | NHTSA-10000-2 | Universal Vehicle Adaptor | U-V-A #2 | 2 |
| 4 | NHTSA-10000-3 | Face Plate | H-V #2 | 3 |
| 4 | NHTSA-10000-4 | Outrigger Retainer Cap | O-R-C #2 | 4 |
| 2 | NHTSA-10000-5 | Outrigger | S-O #1 | 5 |
| 4 | NHTSA-10000-6 | Outrigger Table | H-V #1 | 6 |
| 1 | NHTSA-10-7K | Hardware Kit | R-B-A #2 & O-E-A #1 | All nuts, bolts, and washers as called out |
| 4 | NHTSA-10-8 | Skid Pad | H-S-P #1 | Hemispherical Outrigger Skid Pad |
| 4 | INHTSA-10-9 | Skid Pad adaptor | O-S-P-A #1 | Hemispherical Outrigger Skid Pad adaptor |
