A watertight structure capable of withstanding water pressures of up to 490kPa .Corrosion-resistant version with stainless steel case.
ASW -A series are waterproof acceleration transducers to withstand against water pressures up to 490kPa. Even small-sized these acceleretion transducers ensure reliable measurements under harsh operating environments. In addition, corrosion-resistant version with stainless steel case is also available.| Model | Rated Capacity (Reference Value) |
Frequency Response (at 23??C ) |
|---|---|---|
| ASW- 1A | ??9.807m/s 2 (??1G) | DC to 40Hz Sensitivity Deviation: ??5% |
| ASW- 2A | ??19.61m/s 2 (??2G) | DC to 60Hz Sensitivity Deviation:??5% |
| ASW- 5A | ??49.03m/s 2 (??5G) | DC to 100Hz Sensitivity Deviation:??5% |
| ASW-10A | ??98.07m/s 2 (??10G) | DC to 1kHz Sensitivity Deviation: ??5% |
| ASW-20A | ??196.1m/s 2 (??20G) | DC to 250Hz Sensitivity Deviation:??5% |
| Performance | |
|---|---|
| Rated Capacity | See table above |
| Nonlinearity | Within??0.1% RO |
| Hysteresis | Within??0.1% RO |
| Rated Output | 0.5 mV/V (1000??m/m) or more |
| Environmental Characteristics | |
| Safe Temperature Range | -15 to 65??C |
| Electrical Characteristics | |
| Safe Excitation Voltage | 6V AC or DC |
| Recommended Excitation Voltage | 1 to 3V AC or DC |
| Input Resistance | 122???1.6% |
| Output Resistance | 122???1.6% |
| Cable | 4-conductor (0.08mm 2 ) chloroprene shielded cable, 4 mm diameter by 5 m long, terminated with connector plug |
| Underwater application possible through use of KYOWA cable connection kit JB-200A |
|
| (Shield wire is not connected to mainframe.) | |
| Mechanical PropertiesConnector | |
| Safe Overload Rate | 300% |
| Frequency Response Range | See table above |
| Transverse Sensitivity | ??4% |
| Withstand Water Pressure | 490.3 kPa |
| Material: Case | Corrosion-resistant aluminum, |
| anodic acid coating | |
| Weight | Approx. 40 g (Excluding cable) |
