PDV-A
Corrosion Resistance with Built-in Variable Damping Mechanism
PDV-A series pressure transducers have diffusional semiconductor strain gages on a silicon diaphragm. PDV-A transducers detect pressures as resistance variation and then amplify this singal by built-in amplifier.
?? High frequency response
?? Highly accurate
?? High sensitivity
?? Noise resistant
?? Voltage output of 5 V (PDV-A)
?? Compact and lightweight
Note
(1) Use the transducer with general air.
(2) If water or any other liquid enters the low-pressure line the transducer gets out of order.
Model |
Rated Capacity |
PDS-10GA |
1kPa |
PDS-25GA |
2.5kPa |
PDS-50GA |
5kPa |
PDS-70GA |
7kPa |
Performance |
Rated Capacity |
See table above. |
Nonlinearity |
Within??0.5% RO (within??0.7% with 25GA) |
Hysteresis |
Within??0.3% RO |
Rated Output |
??5V (PDV-10 to 70GA) |
Rated Output Accuracy |
??1.0% RO (PDV-10 & 25GA) |
??1.5% RO (PDV-50GA) |
??2.0% RO (PDV-70GA) |
Environmental Characteristics |
Safe Temperature Range |
-20 to 70??C |
Safe Humdity Range |
20 to 85% RH (0 to 50??C) |
Compensated Temperature Range |
0 to 50??C |
Temperature Effect on Zero Balance |
Within??0.1% RO/??C (PDS-10GA) |
Within??0.08% RO/??C (PDS-25 to 70GA) |
Temperature Effect on Output |
Within??0.1%/??C (PDS-10GA) |
Within??0.08%/??C (PDS-25 to 70GA) |
Pressure Medium |
General air (non-corrosive gas) |
Electrical Characteristics |
Load Resistance |
5 k?? or more (PDV-A) |
Bridge Output Resistance |
2 to 6 k?? (PDV-A) |
Power Supply |
PDV-A : 12V DC (11 to 15 V), 30 mA or less |
Cable |
PDV-A : 4-conductor (0.05 mm2) chloroprene shielded cable,
3 mm diameter by 3 m long, bared at the tip
|
Mechanical Properties |
Safe Overload Rating |
300% (600% with PDS-10GA) |
Maximum Line Pressure |
100kPa |
Natural Frequency |
Approx. 1.7 kHz |
Weight |
Approx. 100 g |
Posture Effect |
Zero drift within??0.3%(??0.8% with 10GA) |
when inclined by 90?? referring to horizontal condition |
Internal Volume |
High side |
Approx. 0.2 x 10 -6 m 3 (0.2 mL) |
Low side |
Approx. 1 x 10-6 m3 (1 mL) |
Pressure Connection |
4.7 mm diameter volute joint |
