PHS-B
PHS-A series pressure transducers have the thin-film strain gage and temperature-compensating resistive membrane formed directly on the diaphragm by sputtering and photo-lithography, thereby enabling
accurate temperature compensation even at high temperatures.
?? High stability at high temperature
?? Possible to measure absolute pressure
?? Usable at both high and low temperatures
* TEDS-installed versions can be manufactured. Inquiries are welcome.
Model |
Rated Capacity |
Natural Frequency
(Approx.) |
PAB-A-200KP |
200kPa abs. |
5kHz |
PAB-A-500KP |
500kPa abs. |
7kHz |
PAB-A-1MP |
1MPa abs. |
20kHz |
PAB-A-2MP |
2MPa abs. |
30kHz |
PHS-B-5MP |
5MPa abs. |
50kHz |
PHS-B-10MP |
10MPa abs. |
70kHz |
PHS-B-20MP |
20MPa abs. |
100kHz |
Performance |
Rated Capacity |
See table above |
Nonlinearity |
Within??0.2% RO |
Hysteresis |
Within??0.2% RO |
Rated Output |
1.5 mV/V (3000??m/m) or more |
Environmental Characteristics |
Safe Temperature Range |
-196 to 230??C |
Compensated Temperature Range |
-30 to 200??C |
Temperature Effect on Zero Balance |
Within??0.02% RO/??C |
Temperature Effect on Output |
Within??0.015%/??C |
Electrical Characteristics |
Safe Excitation Voltage |
15V AC or DC |
Recommended Excitation Voltage |
1 to 10V AC or DC |
Input Resistance |
750?? to 1000?? |
Output Resistance |
750?? to 1000?? |
Cable |
4-conductor (0.09mm 2 ) fluoroplastic shielded cable,
3 mm diameter by 5 m long, bared at the tip
|
(Shield wire is not connected to mainframe.) |
Mechanical PropertiesConnector |
Safe Overload Rating |
150% |
Natural Frequency |
See table above |
Material |
Case : SUS (metallic finish).
Liquid-contacting part : SUS 630 |
Weight |
Approx. 130g (excluding cable) |
Mounting Screw |
G3/8, male |
Gasket (mild copper)
