Compact, Lightweight, Low price For Measurement of Tensile Force of Rope
LTR-S-SA1 series load cells are suitable for measurement of tensile force of rope. Since the hook at one end revolves together with the rope which may revolve due to twisting, easy installation and handling are ensured.| Model | Rated Capacity |
|---|---|
| LTR-S-20KNSA1 | 20kN |
| LTR-S-30KNSA1 | 30kN |
| LTR-S-50KNSA1 | 50kN |
| Performance | |
|---|---|
| Rated Capacity | See table above |
| Nonlinearity | Within??0.5% RO |
| Hysteresis | Within??0.5% RO |
| Rated Output | Approx. 1mV/V (2000??m/m) |
| Environmental Characteristics | |
| Safe Temperature Range | -20 to 70??C |
| Compensated Temperature Range | -10 to 60??C |
| Temperature Effect on Zero Balance | Within??0.05% RO/??C |
| Temperature Effect on Output | Within??0.05%/??C |
| Electrical Characteristics | |
| Safe Excitation Voltage | 12V AC or DC |
| Recommended Excitation Voltage | 1 to 5V AC or DC |
| Input Resistance | 350???2% |
| Output Resistance | 350???2% |
| Cable | 4-conductor (0.3 mm 2 ) chloroprene shielded cable, 7.6 mm diameter by 5 m long, terminated with connector plug |
| (Shield wire is not connected to mainframe.) | |
| Mechanical Properties | |
| Safe Overload Rating | 150% |
| Static Breaking Overload Rating | 200% (150% with 50KNSA1) |
| Weight | Approx. 3.6 kg(not including cable) |
