Compact, Lightweight Tension/Compression Load Cells
Compact and lightweight LUR-A-S1 series is easy to use tension/compression load cells, which can be used in various fields ranging from production lines to experiments.| Model | Rated Capacity | Natural Frequency(Approx.) |
|---|---|---|
| LUR-A-50NSA1 | ??50N | 2kHz |
| LUR-A-100NSA1 | ??100N | 4kHz |
| LUR-A-200NSA1 | ??200N | 5kHz |
| LUR-A-500NSA1 | ??500N | 9kHz |
| LUR-A-1KNSA1 | ??1kN | 14kHz |
| LUR-A-2KNSA1 | ??2kN | 20kHz |
| Performance | |
|---|---|
| Rated Capacity | See table above |
| Nonlinearity | Within??0.5% RO |
| Hysteresis | Within??0.5% RO |
| Rated Output | ??0.5 mV/V (??1000??m/m) or more (LUR-A-100NSA1 to 2KNSA1) |
| Approx. ??0.4 mV/V (??800??m/m) (LUR-A-50NSA1) | |
| Environmental Characteristics | |
| Safe Temperature Range | -10 to 70??C |
| Compensated Temperature Range | 0 to 70??C |
| Temperature Effect on Zero Balance | Within??0.05% RO/??C (LUR-A-100NSA1 to 2KNSA1) Within??0.1% RO/??C (LUR-A-50NSA1) |
| Temperature Effect on Output | Within??0.05%/??C (LUR-A-100NSA1 to 2KNSA1) Within??0.1% /??C (LUR-A-50NSA1) |
| Electrical Characteristics | |
| Safe Excitation Voltage | 7V AC or DC |
| Recommended Excitation Voltage | 1 to 2V AC or DC |
| Input Resistance | 350???2% |
| Output Resistance | 350???2% |
| Cable | 4-conductor (0.3 mm 2 ) chloroprene shielded cable, 3 mm diameter by 5 m long, terminated with NDIS connector plug |
| Mechanical Properties | |
| Safe Overload Rating | 150% |
| Natural Frequency | See table above |
| Weight | Approx. 80 g (not including cable) |
