| Major Properties |
|
| Materials Resistive element |
P type Si |
| Materials Base |
Polyimide |
| Operating temperature in combination with major adhesives after curing (°C) |
EP-340：-50 to 150 ºC
CC-33A：-50 to 120 ºC |
| Operating temperature in combination with major leadwire cables (°C) |
Silver-covered copper wires: -50 to 150ºC |
| Self-temperature-compensation (°C) |
- |
| Applicable linear expansion coefficients (×10^-6/℃) |
- |
| Strain limits at normal temp. (approx. %) |
0.15 |
| Fatigue lives at normal temp. (times) |
2x10^6 (±1000 μm/m) |
