| Major Properties | |
|---|---|
| Materials Resistive element |
1-element: P type Si 2-element: P type Si and N type Si (2-element structure) |
| Materials Base | Polyimide |
| Operating temperature in combination with major adhesives after curing (°C) | CC-33A: -50 to 120ºC EP-340: -50 to 150ºC |
| Operating temperature in combination with major leadwire cables (°C) | - |
| Self-temperature-compensation (°C) |
1-element: - 2-element: 20 to 50 |
| Applicable linear expansion coefficients (×10^-6/℃) |
1-element: - 2-element: 11 |
| Strain limits at normal temp. (approx. %) |
1-element: 0.3 2-element: 0.15 |
| Fatigue lives at normal temp. (times) | 2x10^6 (±1000 μm/m) |
