| Major Properties | |
|---|---|
| Materials Resistive element | CuNi alloy foil (120Ω) NiCr alloy foil (350Ω) |
| Materials Base | Polyimide |
| Operating temperature in combination with major adhesives after curing (°C) | CC-33A: -196 to 120ºC EP-340: -55 to 120ºC |
| Operating temperature in combination with major leadwire cables (°C) | Vinyl-coated normal-temperature low-noise 3-wire cable (L-13): -10 to 80ºC |
| Self-temperature-compensation (°C) | 10 to 100ºC |
| Applicable linear expansion coefficients (×10^-6/℃) | 11, 16, 23 |
| Strain limits at normal temp. (approx. %) | 0.5 |
| Fatigue lives at normal temp. (times) | 1x10^4 (±1500μm/m) |
