| Major Properties | |
|---|---|
| Materials Resistive element | NiCr alloy foil |
| Materials Base | Polyimide |
| Operating temperature in combination with major adhesives after curing (°C) | PC-600: -196 to 150ºC CC-33A: -196 to 120ºC |
| Operating temperature in combination with major leadwire cables (°C) | Vinyl-coated normal-temperature low-noise 3-wire cable (L-13): -10 to 80ºC |
| Self-temperature-compensation (°C) | 0 to 150ºC |
| Applicable linear expansion coefficients (×10^-6/℃) | 11, 16, 23 |
| Strain limits at normal temp. (approx. %) | 1.0 |
| Fatigue lives at normal temp. (times) | 1x10^4 (±1500μm/m) |
