| Physical | |
|---|---|
| Dimensions(excl. antenna) | 37.2cm x 10.4cm x 21.7cm |
| Weight | 3.1kg |
| Processor | Quad core Cortex-A72 64-bit |
| Screen | 7” damage and scratch - resistant touchscreen display |
| Interfaces | RJ-45 Ethernet IP radio 10-16.8 V DC passive PoE Charging 12-24 V DC input |
| Enclosure | Ruggedised with shock protection |
| Charging/Battery | |
|---|---|
| Battery | Rechargeable lithium ion battery (14.4V, 6.8Ah, 98Wh) |
| Testing duration | 6 hours of continuous running |
| Charging | 0-80% in 2 hours* Mains charging: 90-264V AC input IEC 320-C14 input connector |
| Communication | |
|---|---|
| Compatibility | Radio modules available for TrackFi PowerMesh, TrackFi and Link Pro Others available upon request |
| Range | 150m - typical distance with direct line of sight |
| Environment | |
|---|---|
| Operating temperature | Ambient (operating): 0°C to 50°C (32°F to 122°F) |
| Moisture protection | IPX4 |
