PDS-A
For Wind Pressure Measurement
PDS-A series pressure transducers have diffusional semiconductor strain gages on a silicon diaphragm. PDS-A transducers detect pressures as resistance variation and then convert this variation to electrical signals. These signals are indicated by KYOWA signal conditioners.
?? High frequency response
?? Highly accurate
?? High sensitivity
?? Noise resistant
?? Compact and lightweight
Model |
Rated Capacity |
PDS-10GA |
1kPa |
PDS-25GA |
2.5kPa |
PDS-50GA |
5kPa |
PDS-70GA |
7kPa |
Performance |
Rated Capacity |
See table above. |
Nonlinearity |
Within??0.5% RO (within??0.7% with 25GA) |
Hysteresis |
Within??0.3% RO |
Rated Output |
??7 to 23 mV (PDS-10GA) |
??13 to 23 mV (PDS-25 to 70GA) |
Rated Output Accuracy |
??1.0% RO (PDS-10 & 25GA) |
??1.5% RO (PDS-50GA),??2.0% RO (PDS-70GA) |
Environmental Characteristics |
Safe Temperature Range |
-20 to 70??C |
Safe Humdity Range |
20 to 85% RH (0 to 50??C) |
Compensated Temperature Range |
0 to 50??C |
Temperature Effect on Zero Balance |
Within??0.1% RO/??C (PDS-10GA) |
Within??0.08% RO/??C (PDS-25 to 70GA) |
Temperature Effect on Output |
Within??0.1%/??C (PDS-10GA) |
Within??0.08%/??C (PDS-25 to 70GA) |
Pressure Medium |
General air (non-corrosive gas) |
Electrical Characteristics |
Initial Unbalance |
Within ??10 mV |
Bridge Output Resistance |
2 to 6 k?? |
Power Supply |
10V DC (9.5 to 15 V), 5 mA or less |
(Bridge power supply of signal conditioner can be used.) |
Cable |
PDS-A: 4-conductor (0.05 mm 2 ) chloroprene shielded cable,
3 mm diameter by 3 m long, terminated with connector plug
|
(Shield wire is not connected to mainframe.) |
Mechanical Properties |
Safe Overload Rating |
300% (600% with PDS-10GA) |
Maximum Line Pressure |
100kPa |
Natural Frequency |
Approx. 1.7 kHz |
Weight |
Approx. 40 g |
Posture Effect |
Zero drift within??0.3%(??0.8% with 10GA) when inclined |
by 90?? referring to horizontal condition |
Internal Volume |
High side: Approx. 0.2 x 10 -6 m 3 (0.2 mL) |
Low side: Approx. 1 x 10 -6 m 3 (1 mL) |
Pressure Connection |
4.7 mm diameter volute joint |
*TEDS installation not possible.
