KCH
The unique design simplifies gage bonding, wiring and moisture-proofing work in the field. In addition, the metal case protects the strain gage and significantly improves reliability compared with conventional gages. Using stud bolts and adhesive, the gages can be mounted to the bottom and side plate of tank for strain measurement, to a hopper or tank for weight measurement, to the shaft of a truck for tare weight measurement or in any similar applications where the gages need to be protected against moisture, water or small stones. (Patented)
Applicable Adhesives and Operating Temperature Range after Curing
EP-34B |
-40 to 100??C |
CC-33A |
-40 to 100??C |
Relay Cables (for KCH-5A-BJ/SJ) (Option)
Type |
TN-29 |
TN-30 |
TN-31 |
TN-32 |
TN-33 |
Cable |
2m |
3m |
7m |
10m |
12m |
Cable cover |
1.5m |
2.5m |
6.5m |
9.5m |
11.5 |
Other |
With waterproof connector jack (R04-J6-F6.8); the other end is bared. |
