  • LCD-A-S1 to S9

    For Measurement of Loads to Pillow Block

    Having a flat top and bottom, LCD-A-S series rectangular compression load cells enable stable installation of a flat board. Can be used for weighing systems of waste and ash cranes or for measurement of compression loads of pillow blocks placed on them.
    Features
    ?? Hermetically-sealed structure
    PDF Download
    Specifications
    Model Rated Capacity Weight(Approx.)*
    LCD-A-30KNS1 30kN 22kg
    LCD-A-30KNS2 28kg
    LCD-A-30KNS3 28kg
    LCD-A-50KNS4 50kN 35kg
    LCD-A-50KNS5 33kg
    LCD-A-50KNS6 35kg
    LCD-A-50KNS7 40kg
    LCW-C-50KN30SA3 100kN 40kg
    LCW-C-50KN40SA3 40kg
    Performance
    Rated Capacity See table above
    Nonlinearity Within??1% RO
    Hysteresis Within??1% RO
    Rated Output Approx. 1 mV/V (2000??m/m) or more
    Environmental Characteristics
    Safe Temperature Range -20 to 80??C
    Compensated Temperature Range -10 to 70??C
    Temperature Effect on Zero Balance Within??0.01% RO/??C
    Temperature Effect on Output Within??0.01%/??C
    Electrical Characteristics
    Safe Excitation Voltage 15V AC or DC
    Recommended Excitation Voltage 1 to 10V AC or DC
    Input Resistance 350???5%
    Output Resistance 350???5%
    Cable 4-conductor (0.3 mm 2 ) chloroprene shielded cable,
    8 mm diameter by 10 m long, bared at the tip
    (Shield wire is not connected to mainframe.)
    Mechanical Properties
    Safe Overload Rating 150%
    Weight See table above (not including cable)
    Protection Rating IP64 (Splashproof type conforming to JIS C 0920)
