High Strength,Easy to Handle High Reliability,High Stability
These series of tension load cells can be used as detectors for jib crane weighing systems and for general tension measurement.| Model | Rated Capacity | Weight(Approx.)* |
|---|---|---|
| LTA-C-20KNS | 20kN | 5kg |
| LTA-C-50KNS | 50kN | 5.5kg |
| LTA-C-100KNS | 100kN | 11kg |
| LTA-C-200KNS | 200kN | 21kg |
| LTA-C-300KNS | 300kN | 35kg |
| LTA-C-500KNS | 500kN | 60kg |
| Performance | |
|---|---|
| Rated Capacity | See table above |
| Nonlinearity | Within??1% RO |
| Hysteresis | Within??1% RO |
| Rated Output | Approx. 0.6 to 0.7 mV/V (1200 to 1400??m/m) |
| Environmental Characteristics | |
| Safe Temperature Range | -20 to 70??C |
| Compensated Temperature Range | -10 to 60??C |
| Temperature Effect on Zero Balance | Within ??0.01% RO/??C |
| Temperature Effect on Output | Within ??0.01%/??C |
| Electrical Characteristics | |
| Safe Excitation Voltage | 12V AC or DC |
| Recommended Excitation Voltage | 12V AC or DC |
| Input Resistance | 350???5% |
| Output Resistance | 350???5% |
| Cable | 4-conductor (0.3 mm 2 ) chloroprene shielded cable, 10 mm diameter by 10 m long, with press-fit terminal |
| (Shield wire is not connected to mainframe.) | |
| Mechanical Properties | |
| Breaking Overload Rating | Approx. 500% |
| Safe Overload Rating | 150% |
| Weight | See table above (not including cable) |
